Casio XJ-A256 Function Guide

10
1. Place the CD-ROM that comes with the projector into your computer’s CD-ROM
drive.
z This will automatically display the CD-ROM menu screen.
2. On the menu screen, click the [Install] button to the right of “Wireless
Connection 3”.
z Follow the instructions on the dialog boxes that appear on the screen.
z If you are running Windows 7 and the “User Account Control” message appears while
installing, click [Yes].
z If you are running Windows Vista and the “User Account Control” message appears while
installing, click [Allow].
z If you are running Windows XP and message shown below appears while installing, click
[Continue Anyway].
Note
After you install Wireless Connection 3, it will start up automatically and start searching for a
projector. If you want to establish a wireless LAN connection between the computer and
projector at that time, perform the procedure under “To use a default SSID to connect a
computer to the projector via wireless LAN” (page 15). If you do not want to establish a
connection, click the close button in the upper right corner of the Wireless Connection 3 window.
You can use the Wireless Connection 3 token wizard to install Wireless Connection 3 on USB memory.
Then you can plug the USB memory to the USB port of any computer and start up Wireless
Connection 3 from there. This means it is not necessary to install Wireless Connection 3 from the
CD-ROM on each computer that will connect with the projector over the wireless LAN.
For more information, see “Using the Token Wizard” (page 37).
Installing Wireless Connection 3
Installing Wireless Connection 3 on a Second and
Subsequent Computers

Casio XJ-A256 Specifications

General

Matrix size	0.65 \
Number of colors	16.78 million colors
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	18 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	±30 °
Aspect ratio	16:10
RS-232 ports	1
Offset	84 %
Throw ratio	1.15 - 2.3:1
Optical zoom	2 x
Zoom capability	Yes
Focal length range	- mm
Service life of light source	20000 h
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1280 x 800 (WXGA)
RMS rated power	1 W
USB connector type	USB Type-A
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
Wi-Fi standards	802.11b, 802.11g
Noise level	35 dB
Noise level (economic mode)	29 dB
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, ITA, JPN, KOR, SWE
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	110 W
Power consumption (typical)	210 W
Power consumption (PowerSave)	0.4 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, Composite, VGA

Weight and Dimensions

Depth	210 mm
Width	297 mm
Height	43 mm
Weight	2300 g
