Casio XJ-A256 Function Guide

44
Simultaneous Wireless LAN Connections with Multiple
Projectors
Problem Cause and Required Action Refer to:
Wireless Connection 3 is
running on my computer,
but the Projector List
dialog box won’t display.
z Make sure all of the projectors are turned on. A
projector can be recognized by a computer even if
“Wireless” is not selected as the projector’s input
source.
–
z Make sure that all of the projectors have wireless
adapters installed (page 41).
z If the projectors and computer are far away from each
other or if there is wall or some other physical
impediment between them, move them closer and/or
remove the impediment.
z If a nearby microwave oven, Bluetooth device, or other
device is interfering with the wireless LAN signal,
relocate the interfering device.
The SSID of the projector
I want to connect to is
not included on the
Projector List dialog box.
z Check the “SSID Broadcast” setting of the projector. If
“Disable” is selected, change the setting to “Enable”.
“To configure projector
network settings and
wireless LAN connection
settings” (page 34)
z If the projector is off, turn it on.
Even though entering the
login code displayed on
the Wireless standby
screen, I get a “Could not
connect to projector.
Connection has been
terminated.” error.
z If there are two or three projectors, make sure that
each one has a different SSID: casiolpj_default1,
casiolpj_default2, casiolpj_default3.
“To switch between Default
SSIDs” (page 30)
z If there are more than three projectors, assign each
one a unique SSID. In this case you can use the
default SSIDs for three of the projectors and configure
security settings for the remainder of the projectors to
assign original SSIDs.
“To configure security
settings” (page 21)

Casio XJ-A256 Specifications

General

Matrix size	0.65 \
Number of colors	16.78 million colors
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	18 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	±30 °
Aspect ratio	16:10
RS-232 ports	1
Offset	84 %
Throw ratio	1.15 - 2.3:1
Optical zoom	2 x
Zoom capability	Yes
Focal length range	- mm
Service life of light source	20000 h
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1280 x 800 (WXGA)
RMS rated power	1 W
USB connector type	USB Type-A
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
Wi-Fi standards	802.11b, 802.11g
Noise level	35 dB
Noise level (economic mode)	29 dB
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, ITA, JPN, KOR, SWE
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	110 W
Power consumption (typical)	210 W
Power consumption (PowerSave)	0.4 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, Composite, VGA

Weight and Dimensions

Depth	210 mm
Width	297 mm
Height	43 mm
Weight	2300 g
