5.1.3. Pull off the rear water nozzle hose to
remove the rear water nozzle.
5.2. Installation Procedure
The installation procedures are reverse to those
for removal.
Note: water injection opening should be opposite
to wiper motor steering shaft.
6. Removal of Rear Wiper Motor
6.1. Removal Procedure
6.1.1. Remove the rear wiper blade and arm
seat cover.
6.1.2. Use a 10# socket wrench to loosen the
nut above the motor, and remove the rear
wiper blade.
Installation torque: 7±1N.m
6.1.3. Pull the wiper motor connector, remove
three fixing bolts of the rear wiper motor
with 10# socket wrench; remove the motor
assembly.
Installation torque: 12±1N.m
6
