Chery S18D Service Manual
II. Body Assembly Dimension
1. Left Front Axonometric Drawing
No. Clearance position
Clearance
value(mm)
Flatness value(mm)
1 Front windshield and ceiling 7±1 ——
2 Front windshield and pillar A 5±1 ——
3 Front door and ceiling 4±1 2±1
4 Front door and rear door (upper)
1
0.5
4
+
−
1
0
0
+
5 Rear door and ceiling 4±1 2±1
6 Rear side windshield and rear door
1
0.5
4
+
−
1
0
0
+
7 Rear side windshield and ceiling 4.5±1 ——
8 Rear door outside handle and rear door 2
-0.5
0
——
9 Rear side windshield and back door
4～5.5
——
10 Tail lamp and fender 2±0.5 ——
11 Rear bumper and fender (upper part) 0
+0.5
0
-0.7
-0.3
+0.7
12 Rear bumper and fender (lower part) 0
0
+0.5
0.7±0.5
13 Door outer trim panel and door clearance 0
0
+0.5
——
14 Rear door and side wall trim panel 5
-1
+1.5
——
15 Front door and rear door(lower part) 4
0
+1
1
0
0
+
16 Front door handle and door 2
+0.5
0
——
17 Front door and side wall trim panel 5
-1
+1.5
——
18 Front door and front fender 4±1 0
+1
0
63
