Chery S18D Service Manual
II. Removal and Installation of Trunk lid
1. Preparations
Tools: plastic screwdriver, socket wrench, cross ratchet wrench and etc.
Material: plastic clip
2. Removal of Trunk lid Trim Board
2.1. Pry up the trim board clearance with a plastic
screwdriver, then remove the clips in
sequence and remove the trunk lid interior
trim board.
2.2.Remove the fixing bolts of license plate lamp
trim board with 10# socket wrench; remove
the license plate lamp trim board.
2.3. Installaiton of trunk lid trim board
Replace the damaged clips and align the clip with
the installation hole; tap them for installation.
Remark: the trim board tapping force shall be
suitable; clean the surface of interior trim board
after installation..
3. Removal and Installation of Luggage boot Lock
3.1. Removal Procedure
3
