Chery S18D Service Manual
4.5. Pry out the pillar C upper panel with plastic
screwdriver.
4.7. Remove the rear seat belt upper and lower
fixing point and rear seat fixing clip with 17#
socket wrench.
Torque: 50±10N.m
4.8. Installation Procedure
The installation procedures are reverse to those for removal.
Note:
1. Keep the seat belt clean and away from oil, check if there is damage of seat belt, adding screw
thread sealant during the mounting of seat belt fixing bolt.
2. The pillar panel shall be fit firmly with the body without any looseness, and it shall also be fit well
with roof and weather strip.
3. The fit clearance between C pillar lower panel and rear doorsill pressure plate shall be even and
less than 1 mm.
II. Removal and Installation of Seats
1. Preparations
Tools: socket wrench
11
