Ⅸ.Installation of Tail Lamp
9.1. Installation Procedure of tail lamp
The installation procedures of tail lamp are
reverse to those for removal.
9.2. Function of tail lamp
9.2.1. Front view
1). Brake lamp/ position lamp (one bulb has two
filaments)
2). Turn lamp
3). Reverse lamp
9.2.2. Rear view
As shown in right figure:
1). Reverse lamp holder
2). Turn lamp holder
3). Brake lamp/ position lamp holder
34
