Chery S18D Service Manual
4.1.3. Remove the two screws on rear end of
hot water pipe with cross screwdriver.
4.1.4. Remove the two screws on front end of
hot water pipe with cross screwdriver.
4.1.5. Tear off the sponge around the water
inlet and outlet pipe and remove the
heater exchanger.
Note: the sponge seal around the housing is
disposable.
4.2. Installation Procedure
The installation procedures are reverse to those
for removal.
After the installation, the system should be
evacuated, proper pressure should be maintained
and anti-freeze agent should be filled to check for
any leakage. Check if the radiator is blocked and
compressed air can be used to clean it.
5. Removal and Installation of Mode Air Door Related Mechanism
5.1. Removal Procedure
5.1.1. Pull out the control motor connector.
52
