Cisco 1109-4PLTE2P User Manual

Control SourceDescriptionLED ColorPort
I/O sideOff— No USB device
discovered.
Green
USB Console
On— USB device
discovered.
I/O SideOff: No USB device
discovered.
Green
USB
On: USB device
discovered.
Table 3: LED Indicators for C1101 and C1109
Control SourceDescriptionColorLED
I/OSystem Power Status
Off: No Power
Green Steady On:
Normal operation
Green Blink: Boot up
phase or in ROM Monitor
mode
Amber Steady on Or
Blink: Some issues with
the system.
Green+AmberPower
I/OVPN Status
Off: No tunnel
Steady on:At least one
tunnel is up
GreenVPN OK
I/OLink Activity
Off: No link
Steady on: Link
Blink: TXD/RXD Data
GreenEthernet Switch GE LAN
Ports
I/OLink Activity
Off: No link
Steady on: Link
Blink: TXD/RXD Data
GreenGE WAN Ports
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
11
Overview of Cisco 1000 Series Integrated Services Routers
LED Indicators
