Cisco 1109-4PLTE2P User Manual

Figure 26: Location in the C111x/C1111X
PoE Module1
Replace the Chassis Cover for C111X and C1111x
To access the internal modules on the router, you must first remove the chassis cover. See the Replacing the
Chassis Cover for instructions on how to remove and later replace the chassis cover on the routers.
Only trained and qualified personnel should be allowed to install, replace or service this equipment. Statement
1030
Warning
Power-off the unit before you begin. Statement 237
Warning
Before opening the unit, disconnect the telephone-network cables to avoid contact with telephone-network
voltages. Statement 1041
Warning
Cisco 1100 Series ISRs have removable covers. Do not run the routers with the cover off. Doing so can cause
the router to overheat very quickly.
Use a number-2 Phillips screwdriver to perform the following tasks.
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
44
Install and Upgrade Internal Modules and FRUs
Replace the Chassis Cover for C111X and C1111x
