Cisco Aironet 1570 Series Outdoor Access Point Hardware Installation Guide
OL-32138-01
APPENDIX
E
Access Point Pinouts
This appendix describes the pin signals of the access point Ethernet connectors, and the power injector
input and output connectors.
Table E-1 describes the pin signals of the access point LAN connector
Table E-2 describes the pin signals for the access point PoE-in Ethernet connector. The Pinouts given in
this table are applicable to AIR-POWERINJ1500. Not all PoE power sources follow these pinouts.
Table E-1 Access Point LAN Connector Pinouts
Pin Number Signal Name
1 Ethernet signal pair (10/100/1000BASE-T)
2
3 Ethernet signal pair (10/100/1000BASE-T)
6
4 Ethernet signal pair (10/100/1000BASE-T)
5
7 Ethernet signal pair (10/100/1000BASE-T)
8
Shield Chassis ground
Table E-2 Access Point PoE-In Ethernet Connector Pinouts for AIR-POWERINJ1500
Pin Number Signal Name
1 Ethernet signal pair (10/100/1000BASE-T) and DC return
2
3 Ethernet signal pair (10/100/1000BASE-T) and DC (+)
6
4 Ethernet signal pair (1000BASE-T) and DC (+)
5
