Cisco Aironet 1570 Series Outdoor Access Point Hardware Installation Guide
OL-32138-01
Chapter 1 Overview
Features of the Access Point
Antennas
All versions of 1570 series access points have 4x4:3 2.4 GHz radios and 4x4:3 5 GHz radios.
AIR-AP1572I Internal Antennas
AIR-AP1572I has four internal dual band antennas. The maximum 2.4 GHz gain is 4 dBi. The maximum
5 GHz gain is 5 dBi.
AIR-AP1572E External Antennas
AIR-AP1572E has four internal dual band antenna ports, to which the following external antennas can
be connected.
Non-Cisco Antennas
Cisco does not support any third-party antennas. RF connectivity and compliance of third party
antennas is the customer’s responsibility. Cisco does not recommend any third-party antennas, and
Cisco Technical Assistance Center will not be able to provide any support for third-party antennas.
Cisco’s FCC Part 15 compliance is only guaranteed with Cisco antennas or antennas that are of the
same design and gain as Cisco antennas.
Antenna Band Operating Frequency Range (MHz) Type Ports
Peak Gain
(dBi)
AIR-ANT2547VG-N Dual 2400 - 2483
5150 - 5875
Omni 1 4 (2G)
7 (5G)
AIR-ANT2569VG-N= Dual 2400 - 2490
5250 - 5925
Omni 1 (?)
AIR-ANT2588P3M-N= Dual 2400 - 2500
5150 - 5900
Directional 3 8 (2G)
8 (5G)
AIR-ANT2513P4M-N Dual 2400 - 2500
5150 - 5900
Directional 4 13 dBi (2G)
13 dBi (5G)
AIR-ANT2420V-N 2.4 GHz 2400 - 2500 Omni 1 2
AIR-ANT2450V-N 2.4 GHz 2400 - 2484 Omni 1 5
AIR-ANT2480V-N 2.4 GHz 2400 - 2484 Omni 1 8
AIR-ANT2413P2M-N= 2.4 GHz 2400 - 2500 Directional 2 13
AIR-ANT5140V-N 5 GHz 5250 - 5875 Omni 1 4
AIR-ANT5180V-N 5 GHz 4900 - 5850 Omni 1 8
AIR-ANT5114P2M-N= 5 GHz 5150 - 5900 Directional 2 14
