F-2
Cisco Aironet 1570 Series Outdoor Access Point Hardware Installation Guide
OL-32138-01
Appendix F Configuring DHCP Option 43
Overview
Overview
This section contains a DHCP Option 43 configuration example on a DHCP server for use with Cisco
Aironet Access Points. For other DHCP server implementations, consult DHCP server product
documentation for configuring DHCP Option 43. In Option 43, use the IP address of the controller
management interface.
Note DHCP Option 43 is limited to one access point type per DHCP pool. You must configure a separate
DHCP pool for each access point type.
Cisco Aironet 1000, 1500, 1532 access points use a comma-separated string format for DHCP Option
43. Other Cisco Aironet access points use the type-length-value (TLV) format for DHCP Option 43.
DHCP servers must be programmed to return the option based on the access point DHCP Vendor Class
Identifier (VCI) string (DHCP Option 60). The VCI strings for Cisco access points that can operate in
lightweight mode are listed in Table F-1.
The following is the format of the TLV block for 1100, 1130, 1200, 1240, 1250, 1300, 1520, and 1532
access points:
• Type: 0xf1 (decimal 241)
• Length: Number of controller IP addresses * 4
• Value: List of WLC management interfaces
Table F-1 Lightweight Access Point VCI Strings
Access Point Vendor Class Identifier (VCI)
Cisco Aironet 1000 series Airespace.AP1200
Cisco Aironet 1100 series Cisco AP c1100
Cisco Aironet 1130 series Cisco AP c1130
Cisco Aironet 1200 series Cisco AP c1200
Cisco Aironet 1240 series Cisco AP c1240
Cisco Aironet 1250 series Cisco AP c1250
Cisco Aironet 1300 series Cisco AP c1300
Cisco Aironet 1500 series Cisco AP c1500
1
1. For controller release 4.1 or later.
Cisco AP.OAP1500
2
, Cisco AP.LAP1510
2
, or
Cisco AP.LAP1505
2
2. For controller release 4.0, the VCI depends on the model.
Airespace.AP1200
3
3. For controller release 3.2.
Cisco Aironet 1520 series Cisco AP c1520
Cisco Aironet 1570 series Cisco AP c1570
