2-14
Cisco Aironet 1570 Series Outdoor Access Point Hardware Installation Guide
OL-32138-01
Chapter 2 Installing the Access Point
Mounting the Access Point
Wall Mounting the Access Point
The optional PMK contains a mounting bracket for wall mounting or pole mounting. You can use the
mounting bracket as a template to mark the positions of the mounting holes for your installation. You
then install the mounting plate, and attach the access point when you are ready. Table 2-1 lists the
materials you will need in addition to the mounting kit.
Ta b l e 2 - 1 Materials Required to Mount Access Point to a Vertical Wall
Caution The mounting surface, attaching screws and optional wall anchors must be able to support a
50-lb (22.7 kg) static weight.
To mount the access point on a vertical wall, follow these instructions:
Step 1 Use the mounting bracket as a template to mark four screw hole locations on the mounting surface.
See Figure 2-8 for the mounting bracket screw hole locations. Use the mounting slotted holes to attach
the unit to the wall.
Materials Required to Mount Access Point to a Vertical Wall In Kit
Ground lug and screws (provided with access point) Yes
Wall Mount Bracket Yes
Four M6 x 12-mm Hex-head Bolts Yes
Two stainless steel band clamps (adjustable 2"–5", 51 mm –
127 mm)
Yes
Two stainless steel band clamps(adjustable 5"–8", 127 mm –
203 mm)
Yes
Crimping tool for ground lug, Panduit CT-720 with CD-720-1
die (http://www.panduit.com)
No
Four wall mounting screws No
Four wall anchors (specified for all material) No
Drill bit for wall anchors No
Electric drill and standard screwdriver No
#6 AWG ground wire No
Shielded outdoor-rated Ethernet (CAT5e or better) cable No
Grounding block No
Grounding rod No
10-mm box-end wrench or socket set No
