Chapter 5 Preparing Your Site for Installation
Site Planning
Physical Characteristics
Be familiar with the physical characteristics of the Cisco ASR 1000 Series Router to assist you in placing
the system at the proper location.
Note For information regarding rack widths supported for ASR 1000 Routers, see the following sections:
• 19 in.—General Rack Selection Guidelines, page 5-16
• 23 in.—Guidelines for 23 in. (Telco) Racks, page 5-17
Table 5-4 shows the weight and dimensions of the Cisco ASR 1000 Series Routers.
Table 5-4 Physical Characteristics of Cisco ASR 1000 Series Routers
Characteristic Cisco ASR 1001
Cisco ASR 1002,
1002-F, and 1002-X
1
Cisco ASR 1004 Cisco ASR 1006 Cisco ASR 1013
Height 1.71 in. (43.43 mm)
—1RU; rack-mount
per EIA RS-310
3.47 in. (88.13 mm)
—2RU; rack-mount
per EIA RS-310
6.95 in. (176.53
mm)—4RU;
rack-mount per
EIA RS-310
10.47 in. (265.43
mm)—6RU;
rack-mount per
EIA RS-310
22.75 in. (57.8
cm)—13 RU
Width 17.3 in. (439.42
mm)
17.25 in. (438.15
mm)
17.25 in. (438.15
mm)
17.25 in. (438.15
mm)
17.25 in. (438.15
mm)
Depth 22.50 in. (571.5
mm) Depth includes
cable-management
brackets; card and
power-supply
handles for
mounting in a
600mm-enclosed
cabinet.
20.75 in. (527.05
mm) Depth includes
cable-management
brackets; card and
power-supply
handles for
mounting in a
600mm-enclosed
cabinet.
22.50 in. (571.5
mm) Depth
includes
cable-management
brackets; card and
power-supply
handles for
mounting in a
600mm-enclosed
cabinet.
22.50 in. (571.5
mm) Depth
includes
cable-management
brackets; card and
power-supply
handles for
mounting in a
600mm-enclosed
cabinet.
22.60 in. (600.2 mm)
Depth includes
cable-management
brackets; card and
power-supply
handles for
mounting in a
600mm-enclosed
cabinet.
Weight • 23.30 lb (10.6
kg) (with dual
AC power and
integrated
daughter card)
• 22.70 lb (10.3
kg) (with dual
DC power and
integrated
daughter card)
• 25 lb (11.35 kg)
fully loaded
• 40 lb (18.143
kg) for a fully
loaded Cisco
ASR 1002
Router or Cisco
ASR 1002-F
Router
• 43.35 lb
(19.662 kg) for
a fully loaded
Cisco ASR
1002-X Router
50 lb (22.679 kg)
fully loaded
75 lb (34.019 kg)
fully loaded
• Loaded with AC
power
supply—184 lb
(83.46 kg)
• Loaded with DC
power
supply—190.6
lb (86.45 kg)
• Total weight
with
superslots—202
lb (91.62 kg)
with AC and
208.60 lb
(94.61 kg) with
DC
