Cisco ASR-920-12SZ-A User Manual

Figure 21: Wall Mount Bracket
Step 2 Secure the bracket to the device with the recommended maximum torque of 10 inch-pounds (1.1 newton meters).
Wall Mount the Device
Install cable guides before mounting the device on the wall.
Note
Step 1 Position the cable guide against the front of the device, and align the four screw holes as shown in the figure.
Step 2 Use a tape measure and level to verify that the device is installed straight and on level.
Step 3 Secure the cable guides with four M6x12mm screws. The recommended maximum torque is 26 inch-pounds (3 newton
meters).
Cisco ASR-920-12SZ-A and Cisco ASR-920-12SZ-D Aggregation Services Router Hardware Installation Guide
40
Install the Router
Wall Mount the Device
