Signal
Name
Pin
TRP0-2
TRP1+3
TRP2+4
TRP2-5
TRP1-6
TRP3+7
TRP3-8
USB Console Port Pinouts
The following table summarizes the USB console port pinouts.
Table 16: Single USB Console Port Pinouts
DescriptionSignal
Name
Pin
+5VDCVccA1
Data -D-A2
Data +D+A3
GroundGndA4
The USB console port +5VDC is input, and operates as an USB peripheral device.
Note
USB MEM Port Pinouts
The following table summarizes the USB MEM port pinouts.
Table 17: Single USB MEM Port Pinouts
DescriptionSignal
Name
Pin
+5VDC
(500mA)
VccA1
Data -D-A2
Cisco ASR-920-12SZ-A and Cisco ASR-920-12SZ-D Aggregation Services Router Hardware Installation Guide
68
Troubleshooting Aids
USB Console Port Pinouts
