CHAPTER 4
Removing and Replacing FRUs
This chapter describes procedures for removing and replacing field-replaceable units (FRUs) from Cisco
Catalyst 8500 Series Edge Platform.
• Removing AC Power Supplies, on page 37
• Installing AC Power Supplies, on page 38
• Removing DC Power Supplies, on page 38
• Installing DC Input Power Supplies, on page 39
• Removing and Replacing Micro-USB, on page 42
• Removing and Replacing a DIMM, on page 42
• Removing and Replacing Fans, on page 45
• Repacking the Router, on page 47
Removing AC Power Supplies
Procedure
Step 1 Ensure that the chassis power switch is in the Standby position.
It is not required to place the chassis power switch in the Standby position if you want to hot-swap
a single power supply.
Note
Step 2 Unplug the power cable from the power supply.
Step 3 Press the retaining latch towards the pull handle, grasp the handle with one hand, and pull the power supply
out of the slot while supporting the weight of the power supply with the other hand.
Step 4 Repeat these steps if it is required to remove the other AC power supply.
Cisco Catalyst 8500 Series Edge Platforms Hardware Installation Guide
37
