A-2
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-01
Appendix A Specifications
Catalyst 4506-E Switch Specifications
Catalyst 4506-E Switch Specifications
Table A-2 lists the Catalyst 4506-E switch specifications.
Switching Components
Backplane 24 Gbps full duplex backplane
Port density 116 10/100/1000 ports when using a Catalyst 4500 Series
Supervisor Engine II-Plus TS, 96 10/100/1000 ports with
other supervisor engines, or 12 10-Gbps X2 ports
Two 10-Gbps Uplinks, and up to 12 10-Gbps ports on
switching module slots
Inline power integrated support, 820 W per switching module
Physical Characteristics
Dimensions (H x W x D) 12.25'' x 17.31'' x 12.50'' in
311.15 mm x 439.7 mm x 317.5 mm
Weight Minimum weight: 32.25 lbs (14.65 kg)
Maximum weight: 75 lbs (34 kg)
Chassis and backplane: 32.25 lbs (14.65 kg)
Fan tray: 2.75 lbs (1.24 kg)
Airflow
Switch Right to left
Power supply Front to back
Power
PoE supplied –48 VDC
Power to Modules and fans 12 VDC
Power to backplane components 3.3 VDC
Redundancy
Supervisor engine no
Power supply 1 + 1
Table A-1 Catalyst 4503-E Switch Specifications (continued)
Item Specification
Ta b l e A-2 Catalyst 4506-E Switch Specifications
Item Specification
Environmental
Temperature, ambient operating
ambient nonoperating and storage
32 to 104°F (0 to 40°C)
–40 to 167°F (–40 to 75°C)
Humidity (RH), ambient (noncondensing):
operating
nonoperating and storage
10 to 90%
5 to 95%
