The following table shows the M12-PWR adapter pinouts.
Table 2: M12-PWR Pinouts
M12 A-CodeWireMicro-FIT 4P
1RED (22 AWG)3
2N/C2
3BLACK (22 AWG)1
4N/C4
Power Sources
The IW9165D is supported on these power sources:
• DC power: 24 to 48 VDC
• Power over Ethernet (PoE): 802.3af (PoE), 802.3at (PoE+), Cisco Universal PoE (Cisco UPOE).
Connect the unit only to DC power source that complies with the safety extra-low voltage (SELV)
requirements in IEC 60950 based safety standards. Statement 1033
Warning
Power Adapters
The IW9165D supports the following DC power adapters::
• PID: IW-PWRADPT-MFIT4P=: Operating: -40°C to +65°C, 60W.
Power Injectors
The IW9165D supports the following power injectors:
• IW-PWRINJ-60RGDMG=: Operating: -40°C to +70°C. Power derating of 60W at 70°C, and 65W at
65°C. Supports 100M/1G/2.5G/5G/10G rates.
To reduce the risk of fire, use only No. 24 AWG or larger telecommunications line cord. Statement 1023
Warning
When the AP is installed outdoors or in a wet or damp location, the AC branch circuit powering the AP should
be provided with ground fault protection (GFCI), as required by Article 210 of the National Electrical Code
(NEC).
Caution
Cisco Catalyst IW9165D Heavy Duty Access Point Hardware Installation Guide
7
