Cisco Firepower 4110 User Manual

Cisco Preparative Procedures & Operational User Guide
© 2016 Cisco Systems, Inc. All rights reserved.
8) Commit the transaction to the system configuration:
Firepower-chassis /security/tacacs/server # commit-buffer
4.4.6 Configure LDAP via GUI
1) Choose Platform Settings > AAA.
2) Click the LDAP tab.
3) For each LDAP provider that you want to add:
a) In the LDAP Providers area, click Add.
b) In the Add LDAP Provider dialog box, complete the following fields:
Name
Description
Hostname/FDQN (or IP
Address) field
The hostname or IP address on which the LDAP provider resides. If
SSL is enabled, this field must exactly match a Common Name
(CN) in the security certificate of the LDAP database.
Order field
The order in which the Firepower eXtensible Operating System
uses this provider to authenticate users.
Enter an integer between 1 and 16, or enter lowest-available or 0
(zero) if you want the Firepower eXtensible Operating System to
assign the next available order based on the other providers defined
in Firepower Chassis Manager or the FXOS CLI.
Bind DN field
The distinguished name (DN) for an LDAP database account that
has read and search permissions for all objects under the base DN.
The maximum supported string length is 255 ASCII characters.
Base DN field
The specific distinguished name in the LDAP hierarchy where the
server should begin a search when a remote user logs in and the
system attempts to get the user's DN based on their username. The
length of the base DN can be set to a maximum of 255 characters
minus the length of CN=$userid, where $userid identifies the
remote user attempting to access Firepower Chassis Manager or the
FXOS CLI using LDAP authentication.
This value is required unless a default base DN has been set on the
LDAP tab.
Port field
The port through which Firepower Chassis Manager or the FXOS
CLI communicates with the LDAP database. The standard port
number is 389.
Enable SSL check box
If checked, encryption is required for communications with the
LDAP database. If unchecked, authentication information will be
sent as clear text.
LDAP uses STARTTLS. This allows encrypted communication
using port 389.
Filter field
The LDAP search is restricted to those user names that match the
defined filter.
This value is required unless a default filter has been set on the

Cisco Firepower 4110 Specifications

General

Brand	Cisco
Model	Firepower 4110
Category	Firewall
Language	English
