Cisco Preparative Procedures & Operational User Guide
© 2016 Cisco Systems, Inc. All rights reserved.
An LDAP attribute that stores the values for the user roles and
locales. This property is always a name-value pair. The system
queries the user record for the value that matches this attribute
name.
This value is required unless a default attribute has been set on the
LDAP tab.
The password for the LDAP database account specified in the Bind
DN field. You can enter any standard ASCII characters except for
space, § (section sign), ? (question mark), or = (equal sign).
The LDAP database password repeated for confirmation purposes.
The length of time in seconds the system should spend trying to
contact the LDAP database before it times out.
Enter an integer from 1 to 60 seconds, or enter 0 (zero) to use the
global timeout value specified on the LDAP tab. The default is 30
seconds.
This selection identifies the vendor that is providing the LDAP
provider or server details:
• If the LDAP provider is Microsoft Active Directory, select
MS AD.
• If the LDAP provider is not Microsoft Active Directory,
select Open LDAP.
The default is Open LDAP.
c) Click OK to close the Add LDAP Provider dialog box.
4) Click Save.
4.4.7 Configure RADIUS via GUI
1) Choose Platform Settings > AAA.
2) Click the RADIUS tab.
3) For each RADIUS provider that you want to add:
a) In the RADIUS Providers area, click Add.
b) In the Add RADIUS Provider dialog box, complete the following fields:
Hostname/FDQN (or IP
Address) field
The hostname or IP address on which the RADIUS provider
resides.
The order in which the Firepower eXtensible Operating System
uses this provider to authenticate users.
Enter an integer between 1 and 16, or enter lowest-available or 0
(zero) if you want the Firepower eXtensible Operating System to
assign the next available order based on the other providers defined
To Next Page
