SGE2010/SGE2010P Administration Guide 46
Port Configuration
Using the Console
Port Configuration
The Port Configuration Menu provides access to screens where you can view or modify port
settings and PoE settings.
1. Port Settings (see page 46)
2. PoE Settings (see page 47)
0.Back (Select to return to the previous screen.)
From the S
witch Main Menu, pr
ess 3. Port Configuration.
Port Settings
You can use the Port Settings screen to specify the auto negotiation status, port speed, duplex
mode, and flow control settings. You can use the up or down arrow keys to scroll through all the
ports on the Ethernet switch.
To open this screen:
1. From the S
w
itch Main Menu, press 3. Port Configuration.
2. From the Por
t Status Menu, press 2. Poe Status.
