SGE2010/SGE2010P Administration Guide 47
Port Configuration
Using the Console
To configure the ports:
1. Select Edit.
2. Proceed as needed:
a. Press the down a
rrow key to scroll down through the list of ports.
b. Press the right
arrow key to move the cursor from one field to the next within a row.
c. To change a setting, move the cursor to the field, and then press the Spac
e Bar until the
desired setting appears.
3. Press the Esc ke
y to move the cursor to the Action list.
4. Select Sav
e to save your settings
5. When the Oper
ation complete message appears, press the Esc key to move the cursor to the
Action list.
PoE Settings
You can use the PoE Settings screen to specify the priority and PoE settings for each port. You
can use the up or down arrow keys to scroll through all the ports on the Ethernet switch.
To open this screen:
1. From the S
w
itch Main Menu, press 3. Port Configuration.
2. From the Por
t Status Menu, press 2. Poe Settings.
Field Settings
Enable Enable or Disable
Auto Neg. On or Off
Spd/Dpx Auto, 10H, 100H, 10F, 100F, 1000F
Flow Ctrl Auto, On or Off
