Antenna Frequency Band Support and
Gain
RF ConnectorsPart Number/ Description
2.0 dBi, 617-960 MHz
5.0 dBi, 1710-2170 MHz
5.6 dBi, 2300-2700 MHz
6.6 dBi, 3400 - 3800 MHz
6.0 dBi, 4900 - 5925 MHz
One port with GNSS element.
4 x 4G/5G FR1,
SMA(m)
1 x GNSS,
SMA(m)
Cisco 4G (LTE) / 5G (FR1) / GNSS Integrated
Indoor and Outdoor Antenna
(ANT-5-5G4G1-O)
Integrated indoor and outdoor Antenna with
five ports; four ports for 4G (LTE) / 5G (FR1)
and one port for GNSS.
4G/LTE 698-960, 1448-1511, 1710-2400,
2500-2700 MHz
2.6 dBi typical, 3.8 dBi max 698-960 MHz
3.8 dBi typical, 4.3 dBi max 1448-1551
MHz
4.6 dBi typical, 5.5 dBi max 1710-2700
MHz
2 x 4G/LTE,
TNC(m)
1 x GPS
SMA(m)
Cisco Cellular and GPS 3-in-1 Vehicle Mount
and Fixed Infrastructure Antenna
(ANT-3-4G2G1-O)
Fixed Infrastructure Antenna with three ports;
two port 2G/3G/4G and one port GPS Vehicle
Mount.
4G/LTE 698-960, 1710-2700 MHz
2.5 dBi typical 698-960 MHz
2.5 dBi typical 1710-2700 MHz
2 x 4G/LTE,
SMA(m)
1 x GPS
SMA(m)
Cisco Dual LTE-Single GPS Multi-band
Antenna (4G-LTE-ANTM-O-3-B)
Integrated indoor and outdoor Antenna with
three ports; two ports for 2G, 3G, 4G/LTE and
one port for GPS.
4G/LTE:
698-960,1448-1511,1710-2400,2500-2700
MHz
2.6 dBi typical, 3.8 dBi max 698-960 MHz
3.8 dBi typical, 4.3 dBi max 1448-1511
MHz
4.6 dBi typical, 5.5 dBi max 1710-2700
MHz
No GPS element and no WiFi.
2 x 4G/LTE,
TNC(m)
Cisco Cellular 2-in-1 Vehicle Mount and Fixed
Infrastructure Antenna (ANT-2-4G2-O)
Two port 2G/3G/4G antenna with two
elements.
This dual port LTE antenna does not have an
active GPS antenna (compared to
ANT-3-4G2G1-O which does), and is useful
for cases when there is no GPS required, or
when GPS is connected to a completely
separate GPS antenna.
1.5 dBi 698-960 MHz
2 dBi 1448-1511 MHz
3.5 dBi 1710-2700 MHz
N(f)Cisco Outdoor Omnidirectional Antenna for
2G/3G/4G Cellular (ANT-4G-OMNI-OUT-N)
Outdoor Omnidirectional Antenna for
2G/3G/4G Cellular antenna is designed to cover
domestic LTE700/Cellular/PCS/AWS/MDS,
WiMAX 2300/2500, and
GSM900/GSM1800/UMTS/LTE2600 bands.
Cisco Catalyst IR8340 Rugged Series Router Hardware Installation Guide
56
Antenna Selection and Installation
Cellular Antennas
