Passenger safety
1. Open the glove box.
2. Insert the key.
3. Select the position:
"OFF" (deactivation), with "rear facing" child seat,
"ON" (activation), with front passenger or
"forwards facing" child seat.
4. Remove the key keeping the switch in the
new position.
Passenger's front airbag
188
A. Front left seat belt not fastened /
unfastened warning lamp.
B. Front right seat belt not fastened /
unfastened warning lamp.
C. Rear right seat belt unfastened warning
lamp.
D. Rear centre seat belt unfastened warning
lamp.
E. Rear left seat belt unfastened warning
lamp.
F. Passenger's front airbag deactivated
warning lamp.
G. Passenger's front airbag activated warning
lamp.
Seat belts and passenger's
front airbag
183, 189
