INTRODUCTION
D
i g i t a l l y Co m m u n i C a t i n g Sy S t e m
A digitally communicating system consists of a premium indoor furnace or air handler,
an outdoor AC condensing unit or heat pump and touchscreen control. These devices
are linked together and communicate using ClimateTalk
TM
communications protocol.
The touchscreen control is the command center of the communicating HVAC system.
Benets of the communicating system are auto-conguration of the system, the ability
to share information throughout the system for enhanced diagnostics and control, and
simplied wiring. This ensures simple, reliable operation and an accurate installation.
th e r m o S t a t
This thermostat is a digitally communicating touchscreen control designed for use with
compatible Amana
®
and/or Goodman brand Air Handlers or Furnaces, and outdoor AC or
Heat Pump condensing units. This thermostat supports up to 3 stages of heat, 2 stages of
cooling, dual fuel applications, dehumidication, lter maintenance reminders, outdoor
temperature display, and advanced menus. The various options and display areas are
described below.
FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE
INSTALLING OR OPERATING THIS CONTROL AND SYSTEM COULD CAUSE
PERSONAL INJURY AND/OR PROPERTY DAMAGE.
!
NOTES
CAUTION
!
WARNING
!
To prevent electrical shock and/or equipment
damage, disconnect electric power to system
at main fuse or circuit breaker box until instal-
lation is complete.
Thermostat installation and all components
of the control system shall conform to Class II
circuits per the NEC code.
ATTENTION: MERCURY NOTICE
This product does not contain mercury. However, this product may replace a product that
contains mercury.
Mercury and products containing mercury must not be discarded in household trash. Do not
touch any spilled mercury. Wearing non-absorbent gloves clean up any spilled mercury and
place in a sealed container. For proper disposal of a product containing mercury or a sealed
container of spilled mercury, place it in a suitable shipping container.
Refer to www.white-rodgers.com for location to send products containing mercury.
Goodman is not responsible for:
1. Damage or repairs required as a consequence of faulty installation or application.
2. Damage as a result of oods, res, winds, lightning, accidents, corrosive atmosphere or other
conditions beyond the control of Goodman.
3. Use of components or accessories not compatible with this control.
4. Products installed outside the United States or its territories, or Canada.
5. Normal maintenance as described in the installation and operating manual.
6. Replacement parts not supplied or designated by Goodman.
7. Damage or repairs required as a result of any improper use, maintenance, operation or servicing.
8. Failure to start due to interruption and/or inadequate electrical service.
9. Any damage caused by frozen or broken water pipes in the event of equipment failure.
10. Changes in the appearance of the unit that do not aect its performance.
This warranty gives you specic legal rights, and you may also have other rights that may vary from state
to state or province to province.
Installer Name
Installation Date
inDoor eQuiPment
Model #
Serial #
outDoor eQuiPment
Model #
Serial #
