2.2 Features by Model
The table below summarises the features for each model in the ES-U-xxxx-x family.
Table 1 - Features of the ES-U-xxxx-x converters
Power supply types are USB (USB powered), Ext (external power adapter) or Int (internal power supply)
* Power adapter voltages and currents shown in the comments column are for indication only and are
subject to change. To avoid damage, always use the adapter which was provided with your converter to
ensure that you are supplying the correct voltage for operation.
Model Number
Serial Interfaces
Case
Power
Supply
Opto
Isolated
Additional features and Notes
Ports
RS232
RS422
RS485
Metal
Rack
ES-U-1001-A
1
Y
-
-
-
-
USB
-
ES-U-1101-MB
1
Y
-
-
Y
-
USB
Y
Revision B of ES-U-1101-M which
supports higher data throughput
ES-U-1002-A
2
Y
-
-
-
-
USB
-
ES-U-1002-M
2
Y
-
-
Y
-
USB
-
5V 150mA output on 2-way
screw terminal
ES-U-1008B
8
Y
-
-
-
-
USB
-
ES-U-1032-RM
32
Y
-
-
Y
Y
Int
-
RJ45 serial connectors
ES-U-2001B
1
-
Y
Y
-
-
USB
-
Rev B of ES-U-2001
ES-U-2001C
1
-
Y
Y
-
-
USB
-
Rev C of ES-U-2001
ES-U-2101B
1
-
Y
Y
-
-
USB
Y
Rev B of ES-U-2101
ES-U-2101C
1
-
Y
Y
-
-
USB
Y
Rev C of ES-U-2101
ES-U-2101-MB
1
Y
Y
Y
Y
-
USB
Y
6-way screw terminal
ES-U-2002-M
2
-
Y
Y
Y
-
USB
-
5-way screw terminals
ES-U-2102-M
2
-
Y
Y
Y
-
USB
Y
ES-U-2002-M with isolation
ES-U-2104-M
4
-
Y
Y
Y
-
Ext
Y
5VDC (2A) power adapter (barrel
plug) *
ES-U-2008-M
8
-
Y
Y
Y
-
Ext
-
12VDC (1.5A) power adapter (3-
pin terminal) *
ES-U-2016-RM
16
-
Y
Y
Y
Y
Int
-
ES-U-3001-MB
1
Y
Y
Y
Y
-
USB
-
6-way screw terminal, 5V output
Rev B of ES-U-3001-M which
supports higher data throughput
ES-U-3008-RM
8
Y
Y
Y
Y
Y
Int
-
ES-U-3016-RM
16
Y
Y
Y
Y
Y
Int
-
