contents
Page
Guarantee .................................... 2
General Safety Instructions for Power Tools .... 2
Additional Safety Instructions for Radial Saws .. 3
Glossary of Terms for Woodworking ........... 6
Electrical Connections ........................ 7
Assembly and Alignment ...................... 9
Unpacking and Preassembly ................. 9
Alignment Procedure ....................... 13
Page
Location and Function of Controls ............ 21
Basic Saw Operations ........................ 25
Adjustments to Compensate for Wear ......... 31
Trouble Shooting ............................ 35
Maintenance and Lubrication ................. 40
Recommended Accessories ................... 41
Repair Parts ................................. 42
E==
assembly and alignment
TOOLS NEEDED
@
7/16" WRENCH
1/2" WRENCH
3/4" WRENCH
3/4" SOCKET
9/16" SOCKET
7/16" SOCKET
SOCKET EXTENSION
SOCKET WRENCH
MEDIUM SCREWDRIVER
#2 PHILLIPS SCREWDRIVER
PLIERS
FRAMING SQUARE
PENCIL
1/8" HEX "L" WRENCH
3/16" REX "L" WRENCH
miner
FRAMING SQUARE MUST BE TRUE.
Check its accuracy as illustrated below.
CHECKING ACCURACY OF CHECKING ACCURACY OF
INSIDE OF SQUARE OUTSIDE OF SQUARE
REAR EDGE OF FRONT TABLE
(FENCE, SPACER AND BACK _ FENCE
BOARDS REMOVED) _ --/ -- ,
DRAW LIGHT LINE ON / | / DRAW LIGHT LINE ON
TABLE ALONG THIS EDGE _ _ ---_TABLE ALONG THIS EDGE
SHOULD BE NO GAP OR SHOULD BE NO GAP OR
OVERLAP HERE WHEN OVERLAP HERE WHEN
SQUARE IS FLIPPED OVER SQUARE IS FLIPPED OVER
IN DOTTED POSITION IN DOTTED POSITION
11
To Next Page
