D-Link AC750 User Manual

166D-Link DIR-818LW User Manual
Section 4 - SharePort
The Folder screen will display the folder hierarchy on the left, and
le information on the right.
You can perform le operations as described below by using the
buttons at the top of the screen.
To create a new folder:
• Click New Folder in the current directory.
• Enter a folder name in the Create Folder pop-up
window.
• Click OK. The new folder will appear in the left column.
To upload a le:
• Click Upload to upload a le to the current folder.
• In the Upload File pop-up window, browse to the le
you wish to upload.
• Click OK. The file will appear after the browser
refreshes.
To delete a le:
• Tap to check the box next to the les you wish to
delete.
• Click Delete and a dialog box will open.
• Click OK to conrm.
At any time, you can click to return to the main
menu.
File Operations:

D-Link AC750 Specifications

Network Interfaces

LAN interface	Four 10/100Mbps LAN ports
WAN interface	One 10/100Mbps Internet port
Wireless interface (2.4Ghz)	IEEE 802.11b/g/n
Wireless interface (5Ghz)	IEEE 802.11a/n/ac

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Storage temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	10% - 90% non-condensing

Wireless Specifications

Wireless frequency range (2.4Ghz)	2.412GHz ~ 2.483.5GHz
Wireless frequency range (5Ghz)	5.15GHz ~ 5.825GHz
Wireless bandwidth rate IEEE 802.11n	6.5 to 300 Mbps

Dimensions and Weight

Dimensions	156.5 x 113.2 x 53.6 mm (6.16 x 4.46 x 2.11 inches)
Weight	184.7 grams (0.41 lbs)
Antenna type	Internal Antenna
