D-Link AC750 User Manual

91D-Link DIR-818LW User Manual
Section 3 - Conguration
Guest Zone
For each Wireless Band (2.4GHz and 5GHz), check the box
to allow network connectivity between the dierent
zones created.
Check the box to Enable the Guest Zone feature.
The schedule may be set to Always, which will allow
the Guest Zone service to always be enabled. Or select a
schedule from the drop-down menu. You can click New
Schedule and create your own schedule in the Tools >
Schedules section.
Displays the 2.4GHz Band (top) or 5GHz Band (bottom).
Enter a Wireless Network Name (SSID) that is dierent
from your main wireless network.
Select the type of security you would like to enable for
the Guest Zone, or click None.
Click Save Settings.
Enable Routing
Between Zones:
Enable Guest
Zone:
Schedule:
Wireless Band:
Wireless
Network Name:
Security Mode:
The Guest Zone feature will allow you to create temporary zones that can be used by guests to access the Internet. These zones
will be separate from your main wireless network. You may congure dierent zones for the 2.4GHz and 5GHz wireless bands.

D-Link AC750 Specifications

Network Interfaces

LAN interface	Four 10/100Mbps LAN ports
WAN interface	One 10/100Mbps Internet port
Wireless interface (2.4Ghz)	IEEE 802.11b/g/n
Wireless interface (5Ghz)	IEEE 802.11a/n/ac

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Storage temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	10% - 90% non-condensing

Wireless Specifications

Wireless frequency range (2.4Ghz)	2.412GHz ~ 2.483.5GHz
Wireless frequency range (5Ghz)	5.15GHz ~ 5.825GHz
Wireless bandwidth rate IEEE 802.11n	6.5 to 300 Mbps

Dimensions and Weight

Dimensions	156.5 x 113.2 x 53.6 mm (6.16 x 4.46 x 2.11 inches)
Weight	184.7 grams (0.41 lbs)
Antenna type	Internal Antenna
