D-Link AC750 User Manual

4D-Link DIR-818LW User Manual
Section 1 - Product Overview
Hardware Overview
Connections
1
2
3
4
6
5
7
1 USB Port Connect a USB ash drive to share content throughout your network.
2 WPS Button Press the WPS button to start the WPS process. The Power LED will start to blink.
3 LAN Ports (1-4) Connect 10/100/1000 Ethernet devices such as computers, switches, storage (NAS) devices and game consoles.
4 Internet Port Connect your broadband modem to this port using an Ethernet cable.
5 Power Button Press the power button to power the router on and o.
6 Power Port Connect the supplied power adapter to this port.
7 Reset Button Press and hold the reset button with a paper clip for six seconds to reset the router to the factory default settings.

D-Link AC750 Specifications

Network Interfaces

LAN interface	Four 10/100Mbps LAN ports
WAN interface	One 10/100Mbps Internet port
Wireless interface (2.4Ghz)	IEEE 802.11b/g/n
Wireless interface (5Ghz)	IEEE 802.11a/n/ac

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Storage temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	10% - 90% non-condensing

Wireless Specifications

Wireless frequency range (2.4Ghz)	2.412GHz ~ 2.483.5GHz
Wireless frequency range (5Ghz)	5.15GHz ~ 5.825GHz
Wireless bandwidth rate IEEE 802.11n	6.5 to 300 Mbps

Dimensions and Weight

Dimensions	156.5 x 113.2 x 53.6 mm (6.16 x 4.46 x 2.11 inches)
Weight	184.7 grams (0.41 lbs)
Antenna type	Internal Antenna
