D-Link AC750 User Manual

175D-Link DIR-818LW User Manual
Section 5 - Connect a Wireless Client
3. Highlight the wireless network (SSID) you would like to connect to
and click the Connect button.
If you get a good signal but cannot access the Internet, check your
TCP/IP settings for your wireless adapter. Refer to the Networking
Basics section in this manual for more information.
4. The following window appears while your computer tries to
connect to the router.

D-Link AC750 Specifications

Network Interfaces

LAN interface	Four 10/100Mbps LAN ports
WAN interface	One 10/100Mbps Internet port
Wireless interface (2.4Ghz)	IEEE 802.11b/g/n
Wireless interface (5Ghz)	IEEE 802.11a/n/ac

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Storage temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	10% - 90% non-condensing

Wireless Specifications

Wireless frequency range (2.4Ghz)	2.412GHz ~ 2.483.5GHz
Wireless frequency range (5Ghz)	5.15GHz ~ 5.825GHz
Wireless bandwidth rate IEEE 802.11n	6.5 to 300 Mbps

Dimensions and Weight

Dimensions	156.5 x 113.2 x 53.6 mm (6.16 x 4.46 x 2.11 inches)
Weight	184.7 grams (0.41 lbs)
Antenna type	Internal Antenna
