- 19 -
3. IP addresses, Subnet mask IP address, Gateway, and DNS server should be noted
and entered accordingly if you are assigned a static IP address by your ISP. See Table 7:
IP Addresses and Figure 6.
Table 7: IP Addresses
For example:
IP address: 202.178.230.113
Subnet Mask 255.255.255.0
Gateway 202.178.231.1
DNS server: 202.178.225.1
Secondary DNS server: 202.178.244.207
Figure 6: Global Port
4. When finished, click the OK button to complete the setting.
Modifying Local Port Setting (GUI)
5. Select the Local Port tab.
6. Enter the desired IP addresses and Subnet mask.
7. Select Do not distribute IP address to local computers or Distribute IP addresses to
local computers.
8. If Distribute IP addresses to local computers is selected, you must enter the starting
IP address and the DNS server number.
