- 8 -
HOW DOES IT WORK
Cable / XDSL Modem
Single IP Address
IP Sharing for
Cable / XDSL Modem
Small Office / Home Users
10Mbps
Ethernet
10/100Mbps
Ethernet
ISP
Internet
Figure 1: Small Office/ Home Office Setup
