- 23 -
IP Sharing for Cable Modem/ADSL Modem/Ethernet
BIOS Version: 1.00 (1999/10/06)
©Copyrights 1999, all rights reserved.
SRAM Test .......... O
WAN NIC Test ........ O MAC Address: 00 E8 80 C8 20 93
LAN NIC Test ........ O MAC Address: 00 E8 80 C8 00 12
Internet SOAR is ready
System starts up
Welcome to SOAR 1.01
Administrator password:
9. No password is required the first time you log in. Press <ENTER> to enter Configure
mode. The screen prompts you for the following command.
command>
10. Type the SET command to configure your DI-701. Press <ENTER> if you agree with the
default value, or <ESC> to escape.
11. Refer to “Terminal Commands” for a detailed description of terminal commands.
Static Global Port Setting (TP)
Example:
Obtain configuration automatically ?(Yes/No) [Yes] :N
3
IP address for 10M wan : [0.0.0.0]: 202.178.230.113
IP mask for 10M wan: [255.255.255.0]
Device name (0 to 12 characters) <DEFAULT Untitled>: CA2000
Default gateway Router [0.0.0.0]: 202.178.231.1
Primary DNS server [0.0.0.0]: 202.178.225.1
3
When you are entering “NO”, i.e. you select “Static Global Port Setting”, meaning you have an explicit IP address from your ISP
instead of dynamic assigning.
