D-Link DIR-655 User Manual

54D-Link DIR-655 User Manual
Section 3 - Conguration
This will allow you to open a single port. If you would like to open a range of ports, refer to the next page.
Enter a name for the rule or select an application from the drop-down menu.
Select an application and click << to populate the elds.
Enter the IP address of the computer on your local network that you want
to allow the incoming service to. If your computer is receiving an IP address
automatically from the router (DHCP), you computer will be listed in the
Computer Name drop-down menu. Select your computer and click <<.
Enter the port that you want to open. The private and public ports are
usually the same. The public port is the port seen from the Internet side, and
the private port is the port being used by the application on the computer
within your local network.
Select TCP, UDP or Both from the drop-down menu.
The schedule of time when the Virtual Server Rule will be enabled. The
schedule may be set to Always, which will allow the particular service to
always be enabled. You can create your own times in the Tools > Schedules
section.
Select Allow All (most common) or a created Inbound lter. You may create
your own inbound lters in the Advanced > Inbound Filter page.
Name:
IP Address:
Private Port/
Public Port:
Protocol Type:
Schedule:
Inbound Filter:
Virtual Server
Advanced Settings

D-Link DIR-655 Specifications

Device Interface

number of gigabit lan ports	4
number of gigabit wan ports	1
usb port	1

Standards

ieee 802.11n	draft 2.0
ieee 802.11g	yes
ieee 802.3	yes
ieee 802.3u	yes

Weight and Dimensions

item dimensions (width x depth x height)	4.6” x 7.6” x 1.2”
packaging dimensions (width x depth x height)	8.1” x 10.9” x 2.6”
item weight	0.7 lbs
packaging weight	2.0 lbs
