D-Link DIR-655 User Manual

56D-Link DIR-655 User Manual
Section 3 - Conguration
Enter a name for the rule. You may select a pre-dened application from
the drop-down menu and click <<.
This is the port used to trigger the application. It can be either a single port
or a range of ports.
Select the protocol of the trigger port (TCP, UDP or Both).
This is the port number on the Internet side that will be used to access the
application. You may dene a single port or a range of ports. You can use
a comma to add multiple ports or port ranges.
Select the protocol of the rewall port (TCP, UDP, or Both).
The schedule of time when the Application Rule will be enabled. The
schedule may be set to Always, which will allow the particular service to
always be enabled. You can create your own times in the Tools > Schedules
section.
Name:
Trigger:
Trac Type:
Firewall:
Trac Type:
Schedule:
Application Rules
Some applications require multiple connections, such as Internet gaming, video conferencing, Internet telephony and others. These applications
have diculties working through NAT (Network Address Translation). Application Rules makes some of these applications work with the DIR-655.
If you need to run applications that require multiple connections, specify the port normally associated with an application in the Trigger Port eld,
select the protocol type as TCP or UDP, then enter the rewall (public) ports associated with the trigger port to open them for inbound trac.
The DIR-655 provides some predened applications in the table on the bottom of the web page. Select the application you want to use and enable it.

D-Link DIR-655 Specifications

Device Interface

number of gigabit lan ports	4
number of gigabit wan ports	1
usb port	1

Standards

ieee 802.11n	draft 2.0
ieee 802.11g	yes
ieee 802.3	yes
ieee 802.3u	yes

Weight and Dimensions

item dimensions (width x depth x height)	4.6” x 7.6” x 1.2”
packaging dimensions (width x depth x height)	8.1” x 10.9” x 2.6”
item weight	0.7 lbs
packaging weight	2.0 lbs
