DIR-882 AC2600 Wave 2 MU-MIMO Wi-Fi Gigabit Router with
3G/LTE Support and 2 USB Ports
User Manual
Configuring via Web-based Interface
USB Modem
This menu is designed to operate USB modems.
!
Some models of USB modems do not allow performing operations available in this menu
section through the web-based interface of the router.
If the PIN code check for the SIM card inserted into the USB modem is not disabled, the relevant
notification will be displayed in the top right corner of the page.
Figure 157. The notification on the PIN code check.
Click the ENTER PIN button and enter the PIN code in the PIN Input window. Click the Show
icon ( ) to display the entered code. Then click the APPLY button.
Figure 158. The window for entering the PIN code.
Some USB modems in the router mode and Android smartphones in the modem mode have an IP
address from the subnet which coincides with the router's local subnet. In this case, the router's
web-based interface can be unavailable. For correct operation, disconnect the device from the USB
port and reboot the router. Then access the web-based interface, go to the Connections Setup /
LAN page, and change the value of the IP address field on the IPv4 tab (for example, specify the
value 192.168.2.1). Wait until the router is rebooted.
Page 201 of 303

Table of Contents

Other manuals for D-Link DIR-882

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DIR-882 and is the answer not in the manual?

D-Link DIR-882 Specifications

General IconGeneral
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)2533 Mbit/s
WLAN data transfer rate (first band)800 Mbit/s
WLAN data transfer rate (second band)1733 Mbit/s
CertificationFCC B, CE, C-Tick, S Mark
Processor cores2
Built-in processorYes
Product typeTabletop router
Product colorBlack
LED indicatorsLAN, Power, USB, WLAN
Antennas quantity4
VPN supportPPTP/L2TP/IPsec
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
3GNo
USB 2.0 ports quantity1
DSL WAN-
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supportedWindows 10, Windows 7, Windows 8, Windows 8.1
Security algorithmsWPA, WPA2, WPS
Output current2.5 A
Output voltage12 V
AC input voltage100 - 240 V
Power source typeAC
AC input frequency50 - 60 Hz
Storage temperature (T-T)-20 - 65 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)0 - 90 %
Cables includedLAN (RJ-45)
Supported network protocolsIPv4/IPv6
Package depth330 mm
Package width280 mm
Package height90 mm
Package weight1163 g
Pallet width1200 mm
Pallet length1100 mm
Pallet height (air)1227 mm
Pallet height (sea)1955 mm
Pallet gross weight (air)175050 g
Pallet gross weight (sea)281080 g
Quantity per pallet (air)120 pc(s)
Quantity per pallet (sea)200 pc(s)
Shipping (inner) case width296 mm
Shipping (inner) case height364 mm
Shipping (inner) case length477 mm
Shipping (inner) case weight6627 g
Shipping (inner) case net weight5815 g
Number of cartons per pallet (air)24 pc(s)
Number of cartons per pallet (sea)40 pc(s)
Quantity per shipping (inner) case5 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth177.8 mm
Width254 mm
Height44.45 mm
Weight565 g
