Nuclias Connect Software User Manual Installation
Page 6
Mounting
To connect the DNH-100, perform the following procedure:
1. Install the DNH-100 and access points/switches according to the instructions in their documentation.
Access points by default will receive an IP address from the DHCP server.
2. Connect one end of an Ethernet LAN cable to port labeled as Ethernet on the front of the wireless
controller. Connect the other end of the cable to an available RJ-45 port on a switch in the LAN network
segment.
3. Plug one end of the AC power cord into the AC power connector on the back panel of the device. Plug the
other end into an AC power source.
Connecting the Controller
Connecting the Controller
LAN
DHCP Server
Nuclias ConnectAPs Management
Computer
To Next Page
