D-Link ShareCenter DNS-320L User Manual

195
D-Link ShareCenter™ DNS-320L User Manual
Section 4 - Conguration
FTP server
The Application Management section allows you to congure many services for your DNS-320L. The server and service settings include: FTP server,
Add-ons, AFP, NFS, and multimedia services. Let’s begin by looking at conguration options for the FTP server.
Application Management
Set the maximum amount of users that can connect to the FTP server.
Set the amount of time a user can remain idle before being disconnected.
Set the FTP port. Default is 21. If you are behind a router, you will need to
forward the FTP port from the router to the device. Additional ltering and
rewall settings may need to be modied on your router to allow FTP Access
to the device from the Internet. Once the port has been forwarded on the
router, users from the Internet will access the FTP server through the WAN
IP address of the router.
In situations where the device is behind a rewall and unable to accept
incoming TCP connections, passive mode must be used.
Most standard FTP clients like Windows FTP, only support Western European
code page when transferring les. Support has been added for non standard
FTP clients that are capable of supporting these character sets.
Allow you to limit the amount of bandwidth available for each user.
Here the user can enable the SSL/TLS connection only.
Enable or Disable File eXhange Protocol to transfer les from one FTP server
to another.
Note: In order to use FXP (File Exchange Protocol) for server-to-server data
transfer, make sure to change the port from 21 to some other port as listed in
the Port section of the Web UI. Also, make sure to open the corresponding port
on your router and forward that port from your router to the device.
Max User:
Idle Time:
Port:
Passive Mode:
Client Language:
Flow Control:
SSL/TLS:
FXP:

D-Link ShareCenter DNS-320L Specifications

General

RAID levels	0, 1, JBOD
Storage drive size	3.5 \
Storage drive capacity	0 GB
Supported file systems	ext3, FAT32, NTFS
Storage drive interface	Serial ATA, Serial ATA II
Total installed storage capacity	0 TB
Maximum supported storage capacity	6 TB
Number of storage drives installed	0
Number of storage drives supported	2
Wi-Fi	No
Ethernet LAN	Yes
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	TCP/IP, CIFS/SMB, NFS v2/v3, AFP 3.1, HTTP/HTTP, DDNS, NTP, FTP, LLTD, PnP-X, UPnP AV, WebDAV
Compliance industry standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Power requirements	DC 12V / 3A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Compatible operating systems	Windows XP/Vista/7, Mac OS X 10.5, Linux
Number of users	256 user(s)
FireWire 400	FireWire-interface with a data transmission speed of 400 Mbit/s (50MB/s). FireWire is a serial computer bus technology designed as replacement of SCSI and is based on the IEEE 1394 and 1394b standards.
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Product color	Black
LED indicators	HDD, Power, WLAN
Number of fans	1 fan(s)
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Certification	CE, FCC, IC, DLNA

Weight and Dimensions

Depth	144.3 mm
Width	90 mm
Height	193.3 mm
Weight	630 g
