329
D-Link ShareCenter™ DNS-320L User Manual
Section 4 - Conguration
When you click the Open Recording button on the Playback screen, you
are presented with this screen. This screen allows you to see at a glance the
recordings that have been from with the connected cameras.
Depending on your settings, you may see a calendar month or list of recordings
by date at the top left of the screen. Use this calendar or list to select a recording.
In calendar view, days highlighted in green are ones which have a recording.
In calendar view, clicking the
icon selects the current date, allowing you to
browse through calendar months and quickly return to the current date.
The Playback List drop down menu provides various options:
Current Recording - This shows camera videos recorded by the Surveillance
Center module.
Historic Recording - This shows camera recordings backed up by the user. The
number of entries below this will depend on how many recordings you have
backed up.
The Date Time Period section allows you to narrow down the time and date for
which to show recordings.
The timeline at the bottom of the window plots the selected day and displays the
dierent types of recordings and the times they were recorded. The recordings
are all color-coded to dierentiate between the types. You can play any of these
recordings by simply clicking on the point on the timeline that you want to
play. Use the two checkboxes at the bottom of the window to toggle whether
to Show Events and Motion Detection on the graph.
My Surveillance - Recording Information
