xStack
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
49
Static ARP Settings
The Address Resolution Protocol (ARP) is a TCP/IP protocol that converts IP addresses into physical addresses. This table allows
network managers to view, define, modify and delete ARP information for specific devices.
Static entries can be defined in the ARP Table. When static entries are defined, a permanent entry is entered and is used to
translate IP address to MAC addresses.
To view this window, click, Administration > Static ARP Settings, as shown below:
Figure 2 - 46 Static ARP Settings window
To add a new entry, click the Add button, revealing the following window to configure:
Figure 2 - 47 Static ARP Settings – Add window
To modify a current entry, click the corresponding Modify button of the entry to be modified, revealing the following window to
configure:
Figure 2 - 48 Static ARP Settings – Edit window
The following fields can be set or viewed:
Parameter Description
IP Address
The IP address of the ARP entry. This field cannot be edited in the Static ARP Settings – Edit
window.
MAC Address
The MAC address of the ARP entry.
After entering the IP Address and MAC Address of the Static ARP entry, click Apply to implement the new entry. To completely
clear the Static ARP Settings, click the Clear All button.
