Dahua NVR4108-P User Manual

18
Working
Humidity
10℅－90℅
Air
pressure
86kpa－106kpa
Dimensio
n
440mm × 460mm × 89mm
Weight
5.5kg～6.5kg（Exclude HDD）
Installatio
n
Desk installation
1.3.9 NVR72/72-8P Series
Model
NVR72 Series
NVR72-8P Series
System
System
Resource
s
8/16/32/64-channel series product support 8/16/32/64-channel HD
connection respectively. The main stream bandwidth supports
48/96/192/192Mbps.
Operation
System
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode
Video
Compres
sion
H.264/MJPEG
Decode
Capacity
Max supports 32-channel D1, or 16-channel 720P, or 8-channel 1080P
decode.
Video
Video
Input
8/16/32/64-ch network compression video input
Video
Output
1-channel VGA analog video output.
HDMI
1-ch HDMI output. Version number is 1.4
Window
Split
1/4/8/9/16/25/36-window
Audio
Audio
Input
1-ch bidirectional talk input
Audio
Output
1-ch bidirectional talk output
Audio
Compres
sion
G.711a
Alarm
Alarm
Input
8-ch alarm output
Alarm
Output
3-ch alarm output
Relay output. Relay （DC 30V/1A，AC 125V/0.5A（Activation output））
Including one controllable DC +12V output.
