10M/100M/1000Mbps self-adaptive Ethernet port.
Connect to the network cable.
USB2.0 port. Connect to mouse, USB storage device,
USB burner and etc.
It is for general COM debug to configure IP address or
transfer transparent COM data.
High Definition
Media Interface
High definition audio and video signal output port. It
transmits uncompressed high definition video and
multiple-channel data to the HDMI port of the display
device. HDMI version is 1.4.
VGA video output port. Output analog video signal. It
can connect to the monitor to view analog video.
Bult-in Switch. Support PoE.
The 4 PoE series product supports total 48V 50W.
The 8 PoE series product supports total 48V 120W.
One PoE port max supports 15W.
2.2.6 NVR44/44-8P/44-16P Series
The NVR44 series rear panel is shown as below. See Figure 2-29.
Figure 2-24
The NVR44-8P series rear panel is shown as below. See Figure 2-29.
Figure 2-25
The NVR44-16P series rear panel is shown as below. See Figure 2-29.
Figure 2-26
