SiBE18-821_C Special Control
Function 83
3.2 Oil Return Operation
In order to prevent the compressor from running out of oil, the oil return operation is conducted
to recover oil flown out from the compressor to the system side.
3.2.1 Oil Return Operation in Cooling Operation
[Conditions to start]
Referring to the set conditions for the following items, start the oil return operation in cooling.
Cumulative oil feed rate
Timer setting (Make this setting so as to start the oil return operation when the initial
cumulative operating time reaches 2 hours after power supply is turned ON and then every
eight hours.)
Furthermore, the cumulative oil feed rate is computed from Tc, Te, and compressor loads.
Outdoor unit actuator
Oil return preparation
operation
Oil return operation Post-oil-return operation
Compressor
Take the current step as the
upper limit.
52 Hz Full load (→ Low
pressure constant control)
Same as the
“
oil return
operation
”
mode.
Outdoor fan Fan control (Normal cooling) Fan control (Normal cooling) Fan control (Normal cooling)
Four way valve (Y1S) OFF OFF OFF
Main electronic expansion valve
(Y1E)
480 pls 480 pls 480 pls
Subcooling electronic expansion
valve (Y3E)
SH control 0 pls 0 pls
Hot gas bypass valve (Y2S) OFF OFF OFF
Ending conditions 20 sec.
• 3 min.
• Ts – Te < 5°C
• 3 min.
• Pe < 0.6 MPa
• HTdi > 110°C
or
or
Indoor unit actuator Cooling oil return operation
Indoor fan
Thermostat ON unit Remote controller setting
Stopping unit OFF
Thermostat OFF unit Remote controller setting
Electronic expansion valve of
BP unit
Thermostat ON unit SH control
Stopping unit 77 pls
Thermostat OFF unit SH control
To Next Page
