d&b audiotechnik SL Series Rigging Manual

SL-Series rigging components
3.16.4 Truck loading
During transport, the front of the outer touring cart assemblies
should be facing towards the sides of the truck's tail. In this way, a
proper support base is provided when the load is secured using
ratchet straps.
When securing the load, place the ratchet strap or any other
securing device in the middle of the assembly, as shown in the
examples below.
E7490 GSL8/GSL12 Touring cart
Compression mode
E7490 GSL8/GSL12 Touring cart
Tension mode
E7492 SL-SUB/SL-GSUB Touring cart
E7802 KSL8/KSL12 Touring cart
Compression mode
E7495 KSL8/KSL12 Touring cart
Tension mode
E7804 KSL-SUB Touring cart
d&b SL-Series Rigging manual 1.10 en42
