SL-Series array assemblies overview
GSL8/GSL12 Line array 8-deep,
Compression mode setup
Refer to:
Þ Chapter 6 "Compression mode
setup" on page 47.
GSL8/GSL12 Line array 8-deep,
Tension mode setup
Refer to:
Þ Chapter 7 "Tension mode setup"
on page 54.
GSL8/GSL12 Line array 6-deep,
FRONT EXTENSION mode
Refer to:
Þ Chapter 3.3 "SL-Series load beams"
on page 17.
SL-SUB column with 2° splay
between the cabinets
Refer to:
Þ Chapter 8 "SUB columns"
on page 58.
Mixed KSL-System setup
Refer to:
Þ Chapter 9 " Mixed KSL array
configuration" on page 63.
GSL8/GSL12 ground stack setup
Refer to:
Þ Chapter 10.1 "SL-Series TOP
cabinets ground stack" on page 67.
SL-SUB/SL-GSUB ground stack
setup
Refer to:
Þ Chapter 10.2 "SL-SUB/SL-GSUB
ground stack" on page 70.
4 SL-Series array assemblies overview
d&b SL-Series Rigging manual 1.10 en 43
