d&b audiotechnik SL Series Rigging Manual

Safety
1.2 General safety
▪ Installation and setup should only be carried out by qualified
and authorized personnel observing the valid national Rules for
the Prevention of Accidents (RPA).
▪ It is the responsibility of the person installing the assembly to
ensure that the suspension/fixing points are suitable for the
intended use.
▪ Always carry out a visual and functional inspection of the items
before use. In case there is any doubt as to the proper
functioning and safety of the items, these must be withdrawn
from use immediately.
Please also refer to Þ Chapter 14 "Care and maintenance"
on page 76.
1.3 Load capacity/System components and weights
Load capacity - GSL system
NOTICE!
The Z5701 GSL Flying frame together with the Z5702 GSL Load
beam is designed to support a total system weight of 2000 kg
(4409 lb) – SWL including all rigging components.
This allows the suspension of a maximum of 24 x GSL-TOP
cabinets or a SUB column consisting of a maximum of 14 x SL-SUB
cabinets.
The rigging components allow arrays of up to 10 x GSL-TOP
cabinets with a total system weight of 800 kg (1764 lb) to be
flown in any vertical splay angle configuration between the
cabinets.
For any other array configuration the load conditions within the
array have to be checked using the d&b ArrayCalc simulation
software.
Load capacity - KSL system
NOTICE!
The Z5722 KSL Flying frame together with the Z5723 KSL Load
beam is designed to support a total system weight of 1500 kg
(3307 lb) – SWL including all rigging components.
This allows the suspension of a maximum of 24 x KSL-TOP cabinets
or a SUB column consisting of a maximum of 16 x KSL-SUB
cabinets.
The rigging components allow arrays of up to 10 x KSL-TOP
cabinets with a total system weight of 685 kg (1510 lb) to be
flown in any vertical splay angle configuration between the
cabinets.
For any other array configuration the load conditions within the
array have to be checked using the d&b ArrayCalc simulation
software.
The Z5747 KSL-SUB Adapter frame together with the Z5722 KSL
Flying frame allows the suspension of mixed KSL array setups with
a total system weight of 1500 kg (3307 lb) – SWL including all
rigging components.
System components and weights - GSL system
Loudspeakers
Z0750/Z0751, GSL8/GSL12 cabinets 80 kg (176 lb)
Z0760 SL-SUB cabinet 138 kg (304 lb)
Rigging components
(including all additional items of the respective component)
Z5701 GSL Flying frame 44 kg (97 lb)
Z5702 GSL Load beam 29 kg (64 lb)
Z5704 GSL Compression set 44 kg (97 lb)
including Z5703 GSL Compression frame (18.6 kg/41 lb)
Z5707 SL Aiming plate 13.5 kg (29.8 lb)
System components and weights - KSL system
Loudspeakers
Z0780/Z0781, KSL8/KSL12 cabinets 58 kg (128 lb)
Z0785 KSL-SUB cabinet 82 kg (181 lb)
Rigging components
(including all additional items of the respective component)
Z5722 KSL Flying frame 30.3 kg (66.8 lb)
Z5723 KSL Load beam 21 kg (46.3 lb)
Z5724 KSL Compression set 41 kg (90.4 lb)
including Z5725 KSL Compression frame 16 kg (35.3 lb)
Z5707 SL Aiming plate 13.5 kg (29.8 lb)
Z5747 KSL-SUB Adapter frame 38 kg (84 lb)
d&b SL-Series Rigging manual 1.10 en 5
