VLT
®
5000 SyncPos option
MG.10.J4.02 – VLT is a registered Danfoss trade mark
48
Axis parameters with their factory settings
In this parameter group the inputs and outputs are
assigned fixed functions – depending on the ap-
plication. If necessary it is also possible to define a
software end switch here.
If you want the standard settings for all axis para-
meters, simply click on "CONTROLLER"
→→
→→
→
"RESET"
→→
→→
→
"PARAMETERS".
NB!
The global parameters will also be reset to
the factory settings if you do this.
■■
■■
■ "PARAMETERS" → "NAME"
You can also enter a name for each VLT in addition
to the number or change an existing name with this
function. Click on "CONTROLLER"
→→
→→
→
"PARAMETERS"
→→
→→
→ "NAME" and select the VLT
that you want to start in the subsequent dialog
field:
In the field "NAME" enter a name for the VLT (no
longer than 8 characters) or overwrite the existing
name and click on
"OK"
..
..
.
PC Software Interface
